POWERPRO 256SI

acdc-blow
IGPT-PULSE
PILOT-PLASMA
MMA-TIG

The Power PRO 256Si is a top-equipped AC / DC tig for welding both steels and aluminum. The machine also has a 60A plasma cutter that uses the same IGBT power electronics as the TIG.

The power of the plasma cutter is sufficient for excellent ~ 15mm steel and a maximum of ~ 23mm.

The machine is suitable for both enthusiasts and demanding professional welders. Reliability is top notch.

With water-cooled WP18 tig burner as standard.

1.828,00 1.462,00 inc. VAT

Stock level:

in stock

TECHNICAL DATA

IGBT Inverter Type: IGBT
Voltage/phase:  400 V 3 Phase
TIG output type: AC/DC
TIG Start Type: High Frequency Only
Pulse: Yes, Adjustable
Plasma Cutter Arc Start Type: Blow Back (Piston type)
PilotArc: Yes
OK-to-Cut Indicator/Low Air pressure safety: Yes
AC Frequency: 20-250 Hz
AC Balance (cleaning): 10-90%
OCV: 85V
Max Inrush ( I1MAX ) Amps: 40A
Maximum Rated (I1EFF ) Input Amps: 32A
TIG Output Amps/Volts @ Rated Duty Cycle:
  • 250A/20V @ 60% Duty Cycle
  • 200A/18V @ 100% Duty Cycle
Stick Output Amps/Volts @ Rated Duty Cycle:
  • 200A/28V @ 35% Duty Cycle
  • 160A/26.4V @ 60% Duty Cycle
  • 130A/25.2V @ 100% Duty Cycle
Plasma Output Amps/Volts @ Rated Duty Cycle:
  • 60A/104V @ 35% Duty Cycle
  • 50A/100V @ 60% Duty Cycle
  • 40A/96V @ 100% Duty Cycle
TIG AC Amp/Volt Range: 20A-250A; 10.8V-20V
TIG DC Amp/Volt Range: 5A-250A; 10.2V-20V
Stick Amp/Volt Range: 5A-200A; 20.2V-28V
Plasma Amp/Volt Range: 20A-60A; 88V-104V
Start Amps:
  • DC:  5-250A
  • AC:  20-250A
End Amps:
  • DC: 5-250A
  • AC: 20-250A
Down Slope Time: 0-25 Seconds
Up Slope Time: 0-10 Seconds
Preflow time: 0-10 Seconds
Post Flow Time: 0-25 Seconds
OverCurrent Protection: Yes
Duty Cycle Protection: Yes
Air Pressure OK Safety Indicator: Yes
TIG Pulse Frequency: .5-250Hz
TIG Pulse Time On: 10-90%
TIG Pulse Amp Range: 5-95%
Stick Arc Force Control: Yes, 10-100%
Torch Type: PT/iPT 60

DESCRIPTION

The Everlast PowerPro 256Si brings maximum power and performance to the table with its newly redesigned IGBT inverter design by featuring digital control. This increases reliability and accuracy. It’s ideally suited for repairs and maintenance chores when space and portability on the job site or repair truck are real concerns.  The welder features up to 250 amps of AC/DC TIG welding power, and a full 200 amps of stick welding power to handle almost any welding project or task.  The plasma cutter also supplies up to 60 amps of power to cut or trim up any metal to complete the task and features the longer life PT/iPT 60 torch.  The PowerPro series of welders from Everlast are designed for utility use and offer a good value for both hobbyists and professionals who need portable, all-in-one welding and cutting capability.

DOWNLOADS

PRODUCT NOTES

This unit is not designed or intended for Industrial manufacturing or production welding.  If using on a generator, the generator must be rated by the generator manufacturer as producing “clean power”, which is considered to be <5% THD.  The generator should be rated for at least 11,500 watts for best operation.

MINIMUM/MAXIMUM

TIG single pass capability:

  • Steel: 36 gauge-1/2″
  • Aluminum:  24 gauge- 5/16″

Stick electrode diameter capability:

  • 1/16″-5/32″

Plasma Cutting capability* ( with dry air, new consumables, proper air pressure etc.)

  • up to 5/8″ daily use @ 15-20 ipm
  • up to 3/4″ clean cut @ 8-12 ipm
  • up to 1″ severance cut @ 3-5 ipm

*Quality and capacity of cut depends upon consumable orifice size, standoff height, travel speed, etc.
